Universal Garage Door Opener Remote Upgrade / Conversion Kit

Product Description
$75.00
Maximum quantity available reached.

The Genie Universal Dual Frequency Remote Conversion Kit is used to upgrade nearly any model garage door opener to use modern (secure) remotes. This GIRUD-1T comes with one garage door opener 3-button remote and works with all of our current or previous style Genie Intellicode remotes.

  • Universal- works with nearly all model garage door openers that have required safety beams installed
  • Acts as a replacement receiver for older model garage door openers
  • Includes one 3-button remote, one receiver, one transformer, electrical wire (two-wire), and instructions
  • The kit alleviates interference issues with Radio Frequency interference by offering dual frequency to alleviate issues from the land mobile radio communication system used by military bases as part of the homeland security efforts
  • Intellicode access security system provides state-of-the-art security for your home by automatically changing the opener's access code every time the remote operates; helps prevent unauthorized entry
  • Each button on the 3-Button remote can be programmed to other Genie Intellicode model garage door openers/ Intellicode receivers (use the one remote on up to three separate operators)
  • Model GIRUD-1T



 California Residents: Proposition 65 WARNING

Sku: 36359R

 PDF Instructions for the GIRUD-1T Universal Radio Reciever Conversion Kit

Universal Radio Receiver Conversion Kit with Programming Instructions for use with all brands of garage door openers

Customer Information

By purchasing a Universal Radio Receiver Conversion Kit with Rolling Code system, you can be confident that you’re equipping your garage door opener with the best possible defense against the threat of code grabbers.

We’ve broken the installation process into easy-to-follow steps. If at any time during the installation process you have questions, please call the Customer Service department at 1-800-354-3643.



GIRUD-1T Parts Identification and tools for installation

Step 1

Getting Started FIGURE 1

Pre-Installation
The installation process for your Universal Radio Receiver Conversion Kit will vary slightly depending upon your opener’s radio system.

WARNING

The power cord must be unplugged before attaching any wires. Be sure wire ends do not touch each other or other terminals. If your opener is equipped with a Wireless Keypad or you use other access devices such as a mini-remote control, the batteries must be removed from these devices as well.

GIRUD-1T Figure 1 installation instructions

A Unplug, or open the breaker that supplies power to the garage door opener.
WHICH DO YOU HAVE, AN INTERNAL OR EXTERNAL RADIO?

B For openers with internal radios.
• REMOVE batteries from all old remote controls.

C For openers with external radios.
• Disconnect the existing external radio receiver from the garage door opener.

Step 2

Mounting the Universal Receiver FIGURE 2

GIRUD-1T Figure 2 Installation Instructions

A Position the receiver on the ceiling above and in front of the opener (between the opener and the garage door) so that the receiver is at least 2 feet from the opener.

B Mount Receiver using two pan head screws.

NOTE: Do not attach the Receiver to the garage door opener’s mounting hardware. Attaching the Receiver to the mounting bracket or other metal surfaces could cause interference or grounding.

NOTE: Do not remove the circuit board.

Step 3

Connecting Receiver to Door Opener FIGURE 3

GIRUD-1T Figure 3 Installation Instructions Connecting the receiver

A Cut wire; enough to run from the garage door opener terminal strip to the Receiver.
• The location of the terminal strip varies from model to model. It may be located on the back, front or sides of the opener or underneath the light lens. If you cannot locate the terminal strip, please refer to the Owner’s Manual of your opener or contact the manufacturer of the opener.

B Strip and route wires.
• Remove 1/2˝ of insulation from the garage door opener end of the wire.
• Remove 1/4" of insulation from the Receiver end of the wire.
• Route wire from Receiver to garage door opener terminal strip making sure the wire is clear of all moving parts of the door and door hardware.
• Staple wire in place.

NOTE: Drive staples just tight enough to hold the wire. Staples driven too tightly can short circuit the wiring.

C Wire the receiver.
• Connect the STRIPED Wire to “WALLBUTTON” terminal on the Receiver.
• Connect the WHITE Wire to “COMMON” terminal on the Receiver. (Do not tighten screw yet. Another wire will be added later).

D Wire the garage door opener.
• Follow existing wires from Wall Button to the terminal strip on the door opener.
• Connect the WHITE Wire to one of the Wall Button terminals.
• Connect the STRIPED Wire to the other Wall Button terminal.

Step 4

Connecting Receiver to Transformer FIGURE 3

CAUTION: Be sure wire ends do not touch each other or other terminals.

A Cut wire; enough to run from Receiver to transformer.

B Strip and route wires.
• Remove 1/2˝ of insulation from the transformer end of the wire.
• Remove 1/4˝ of insulation from the Receiver end of the wire.

• Route wire from Receiver to the transformer, making sure wire is clear of all moving parts of the door and door hardware.

• Staple wire in place.

NOTE: Drive staples just tight enough to hold the wire. Staples driven too tightly can short circuit the wiring.

C Wire the Receiver.
• Connect STRIPED Wire to “POWER” terminal.
• Connect WHITE Wire to “COMMON” terminal.
• Now tighten the screw.

D Wire the transformer.
• Connect the STRIPED Wire to either terminal.
• Connect the WHITE Wire to the other terminal.

NOTE: It does not matter which wire is connected to which terminal.

E Connect to the power source
• Plug in the garage door opener.
• Plug in the transformer.

Your  Universal Radio Reciever Conversion kit system is now ready to program!

Step 5

Programming the Receiver FIGURE 4

GIRUD-1T Installation figure 4 Programming the receiver



WARNING: During programming, the Door Opener could begin to run. Stay away from moving Door and its parts. To keep Door from moving, close Door using the wall button and disconnect it from Opener by pulling Emergency Release Cord (see Owner’s Manual).

A Locate Learn Code Button and Learn Code Indicator LED on the side of the receiver.


B Press and release Learn Code Button.
• Indicator LED will blink about 2 times
per second.

C Press transmitter button once within 30 seconds.
• Indicator LED stays on.

D Press the same transmitter button again within 30 seconds to set Code.
• Indicator LED turns off.

E Press transmitter button again.
• Door should move.

F Press transmitter button again.
• Door should stop.

NOTE: If you do not perform steps C and D quickly enough, the LED will begin flashing rapidly. Begin programming again at Step B.

NOTE: If the Receiver does not respond properly at any time during programming, check the wiring and connections between the Receiver and transformer.

NOTE: If door opener does not respond properly, check wiring and connections between Receiver and Opener.

G Repeat Steps 5A through 5G for each Transmitter, Wireless Keypad or other access devices to be learned.

Step 6

Transmitter Function

NOTE: After successfully programming the receiver and all transmitters, engage the garage door. (See Owner’s Manual for instructions.)

A Point Transmitter toward opener and press button.
• Door moves.


B Press Transmitter button again.
• Door will stop moving.


C Press Transmitter button again.
• The door will move in the opposite direction. The door will stop automatically at the fully open and fully closed positions.

WARNING: TEST CONTACT REVERSE SYSTEM of your door opener. See your door opener Owner’s Manual for the procedure.

Step 7

Disabling the Old Radio System FIGURE 5

GIRUD-1T Figure 5 Installation instructions disabling the old radio system

FOR ADDITIONAL SECURITY YOU MUST NOW DISABLE THE OLD RADIO SYSTEM.

A Throw away all old remote controls, wireless keypad, and other access devices.
• Make sure batteries have been removed.

B For garage door openers with internal radios.
• Cut off antenna.– Most antennas are thin pieces of wire hanging from the opener. Some are thin strips of metal. If you can’t find the antenna, see your Opener’s Owner’s Manual or contact the manufacturer.

• Change code settings.
– Locate the code switches.
– If they are not obvious, check inside the Light Lens.
• Change the combination of up and down switches in the garage door opener.

NOTE: It is essential that you also change the code settings in case someone may have copied your code.

Instead of switches, some garage door openers had a series of numbered holes with a small strand of metal or wire running across the hole called “punch outs.”To change the code you simply break one or two additional punch outs in the garage door opener. Some garage door openers have no code switches or punch outs. If you are unable to locate the settings or cannot change them, refer to your Opener’s Owner’s Manual or contact the manufacturer of your opener.

C For garage door openers with external radios.
• Remove existing radio receiver.
• Throw away the existing external radio receiver.

Step 8

Erasing Receiver Memory

WARNING: During programming, the Door Opener could begin to run. Stay away from moving Door and its parts. To keep Door from moving, close Door using the wall button and disconnect it from Opener by pulling Emergency Release Cord (see Owner’s Manual).

If a Transmitter becomes lost or stolen or you want to delete a Transmitter, Wireless Keypad or other access devices:

A Press and hold Learn Code Button for 10 seconds or until Learn Code Indicator LED goes out.
• All Transmitter Codes are erased from memory.

B Reprogram Receiver with remaining Transmitters.
• Follow Step 5.

 Step 9 Battery / Visor Clip Installation FIGURE 6

GIRUD-1T instructions figure 6 battery- visor clip installation

• Gently pry off back of transmitter case. Take care when opening.
– Use a ballpoint pen, coin or small screwdriver.
• Remove the old battery and install a new battery of the same type in same position.
• Press the halves of the transmitter together until it snaps closed.

NOTE: FCC and IC CERTIFIED
This device complies with FCC Part 15 and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular situation. If this equipment does cause harmful interference to radio or television reception, which may be determined by turning the equipment OFF and ON, the user is encouraged to try and correct the interference by one or more of the following measures: (a) Re-orient or relocate the receiver antenna, (b) Increase the separation between the opener and receiver, (c) Connect the opener into an outlet on a circuit different from that to which the receiver is connected, and (d) Consult your local dealer. Any modifications or changes to this equipment which are not expressly approved by the manufacturer could void the user's authority to operate the equipment.







QUESTIONS & ANSWERS

Ask a Question
  • Will this work with a model 450?

    The GIRUD is intended for use on Genie openers that have the required safety beams.

  • Is it compatible with Genie Promax 500 ic/b?

    Yes, it is!

  • Will this work with a Genie SilentMax 1000?

    Yes, you could add this to the SilentMax 1000 model.

  • Will this work with a Genie GXL 9500. Also will the hardwire activation switch continue to work with same?

    This conversion kit will work on the GXL 9500 model garage door opener. The wall console will continue to work the same.

  • Is this item compatible with model GIT-A genie?

    Yes, it is.

  • How many remotes will this receiver store?

    The Universal Receiver will hold up to seven remotes.

  • Will this work with Genie model #420?

    No, it will not.

  • Will this work with a Marantec ML 2005 system?

    Yes, it will.

  • I have a 2013 F150 with factory remote on sun visor, will the universal conversion kit work with my visor /

    Yes, it will.

  • My 12V gate opener does not have AC power nearby. What are the power input requirements for this receiver? The Liftmaster 850LM receiver, for example, operates accepts either AC or DC at 9-30 volts. Would DC power attached to the terminals of this product damage it?

    This conversion kit has to be plugged into an outlet.

  • Will this work with the opener model 7055?

    Yes, it will!

  • I have a very old Sears opener(1970s) with no remotes and a non working transmitter wall box,will this work ?

    This will not work on any garage door opener that does not have Safe-T-Beams.

  • how many remotes can you use

    You can program up to seven wireless devices (remotes/ keypads/ vehicles) into the conversion kit.

  • Can this work on a 12 volt system on a gate?

    Yes, this can be attached to certain gate openers. Do you know what model the gate opener is?

  • Does this work for a genie pro 82

    This will work on the Pro 82 if you have Safe-T-Beams installed.

  • Can this be used for a gate that operates on a 12 volt battery?

    What type of gate opener do you have to open the gate?

  • Will this work on an old model 200 opener?

    This will not work on any model that does not have Safe-T-Beams.

  • will this work with an old genie pro 88?

    Yes, it will.

  • Compatible with genie 404

    No, it is not.

  • I have a Genie GS419a garage door opener. I would like to upgrade the opener controller. Is Genie GIRUD-1T Universal Conversion Kit compatible with my 1980's Genie? I would like any upgrade to be able to work from my GM vehicle homelink systems.

    This kit can be added to a garage door opener as long as your unit has safety beams installed.

  • Can this replace the need for the old dipswitch remotes??

    Yes. This Conversion kit uses Intellicode technology.

  • How many transmitters will this support?

    This will hold up to seven wireless devices. (Remotes, Wireless Keypads, In Vehicle Remote Systems).

  • Will this work on a Touch n Go model 100

    No, it will not.

  • Will this work with a 1979 genie garage door opener

    No, it will not.

  • Will this work with model 404?

    No, it will not.

  • Is this unit compatible with the KEP 1/1A keypad?

    The KEP wires to the powerhead of the garage door opener, it would not wire to this conversion kit. If you add this kit to a garage door opener that already has the KEP on it, the KEP keypad will work the same.

  • Do I need to reprogram my cars after doing the upgrade

    Yes, you would need to program the cars to work with this reciever.

  • Is this compatible with a genie model 200 chain drive garage door opener?

    No, it is not.

  • can safety beams be purchased separately to make compatible with a model 200

    We do not have safety beams for the model 200.

  • does this unit replace the one that is with my model 200?

    This cannot be added to any model that does not have safety beams.

  • Will this work with Genie Blue Max 1/3 HP model?

    Yes, it will.

  • Will this work with model GITR-3?

    Yes, it will.

  • Will this integrate with an alladin connect? ie: if I put this on an older opener and then get an alladin can I open an older door via phone app?

    If your garage door opener does not have Safe-T-Beams you cannot add this or Aladdin Connect to it.

  • I have 2 garage doors currently open Manually. Do I only need the one receiver above for both doors or do I get one for each door? Is there anything special I have to buy since they have never had a door opener installed? Any help would be appreciated!

    These can only be added to garage door openers. They will not work with the garage door alone.

  • will this work with Liftmaster 41A4252-7D?

    It should, but to verify we would need some more information about the model you are trying to attach it to. Please contact Genie customer service at 1-800-354-3643.

  • Will this unit work with a Genie Model 200 (circa 1980)?

    No, it will not.

  • What is the estimated opening range of the GIRUD-1T

    This can differ due to surroundings in and around the garage.

  • Will this work with a Genie Screw Driver SD9500 and LiftMaster Keypad?

    The Conversion kit will work to upgrade the SD9500 model garage door opener. It will not work with a LiftMaster Keypad.

  • How many remotes can I program to this receiver? I think there is a limit.

    You can program up to seven remotes (or other wireless devices).

  • Is it compatible with a Raynor 170-7 opener from '93?

    Yes, it is.

  • with two external receivers on both door and one remote control works separately at different times for each other?

    Yes! You will program a different button on the remote to each reciever.

  • One remote control works with two separate kit? I have two door but I need a remote control for both door.

    Yes, if you have the external receiver on both doors, one remote would operate both.

  • how do you program an overhead o3tp remote to this? Do I need to set it to codedoger1 or codedoger 2 to program? Thank you, Vincent

    It should have the red led light showing on the O3T remote to work with this external receiver.

  • I have a girud-1t and moved it to my new home and the power supply got lost in the move. What voltage does it require and where can I get one?

    Please contact Genie customer service at 1-800-354-3643. We do not sell this online as a separate part.

  • With this work on the old Genie model 409

    No, it will not.

  • can i program to work with a 2013 subaru (homelink)?

    Yes, this will program to the in-vehicle remote system, Homelink.

  • will this work with a genie model 820. it does not have the safety beams

    No, it will not.

  • We have 3 garage doors, each are Genie Blue Max. We we need to install 3 kits, or just 1?

    You would need to put a receiver kit on each one if you are trying to make them all have Intellicode technology.

  • Will this work with my Chrysler Pacifica 2019 visor remote?

    Yes, this works with Homelink in vehicle remote systems.

  • Will this work on a genie max blue garage door opener. We only had one remote and the remote no longer works and I can’t find a replacement remote?

    Yes, it will!

  • Does this work with the MyQ smart garage hub?

    You will need to check with LiftMaster on this. It will depend on the garage door opener.

  • Marantecm

    This will work with most Marantec models. Please contact Genie customer service at 1-800-354-3643 to confirm your model.

  • Will this work with a 1991 SD9500 Genie garage door opener?

    Yes, it will.

  • we bought a house with an old Touch N Go 100 opener. The original remote stopped working. Will this work with the original Touch N Go??? So frustrating to find replacement remotes. Please help!

    This conversion kit should not be added to any garage door opener that does not have Safe-T-Beams.

  • I wired the 1998 Craftsman opener to a new Genie Dual Frequency Conversion Kit. Not only does this not work but now the wall button will not work. What am I doing wrong?

    Please contact Genie customer service at 1-800-354-3643 for assistance.

  • Is the transformer needed to connect to an Genie Model 450 or can I connect the three terminals on the GIRUD to the three terminals on the opener? My current receiver connects directly using this connection.

    The Genie 450 does not have Safe-T-Beams, the Conversion kit should not be added to anything without safe-T-Beams.

  • Does this retro kit GIRUD-iT work with Genie Pro screw drive model CM7600IC/A?

    Yes, it will.

  • will it work with Chamberlain remote 953EV/EVC

    No, it will not.

  • I just purchased (and received) the following items: GM3T-R 3-Button Genie Master® Remote (2 Pack) plus 1- Wireless Keyless Entry Keypad GK-R for my older Genie SD9000 door opener. The new remote works wonderfully well but I didn't realize the Keyless Entry is not compatible with the older model opener that has dipswitches. Will the GM3T-R 3-Button Genie Master® Remote and the keyless entry pad work with the Universal Garage Door Opener Remote Upgrade / Conversion Kit, or should I return the remotes? Where does the conversion kit mount? On the Opener or on the ceiling?

    They will all work with the Universal Conversion Kit. It can be mounted either place.

  • Have a genie G2500 that uses dip switches for programming will this work with it

    Yes, this will change it from the dipswitches to Intellicode technology.

  • I would also like a keypad. Is there a genie keypad that will work with this system as well. I need a new receiver and a new keypad to open my existing garage door opener.

    Yes! You can use the Genie wireless keypad, GK-R with this Universal Conversion Kit.

  • Will it fonction with a genie pro88 ?

    Yes, it will.

  • Will it work on a genie GS850

    This will work on any Genie garage door opener that has the Safe-T-Beams attached.

  • Will this be compatible with a Genie Model 200 from 1976?

    No, this will not work with any garage door opener that does not have safe-t-beams.

  • Can this be used to replace a Genie receiver model ACSR3G type ERY?

    Yes, it can.

  • is this compatable with homelinkon fords?

    Yes, it is.

  • Will this work with the Genie Cryptar II Model No. AR -79?

    No, it will not.

  • will this work with a model 400 opener from 1985-86, that does not have any of the new safety devices?

    No, it will not.

  • Will this work with a Wayne Dalton Quantum 3213?

    Yes, it will.

  • Will this work with the Silent Max connect model# 3053 and the several remotes that are already programmed for it? Also, will I need to reprogram my smartphones to use the Alladin remote feature?

    This will work with the 3053 model. You will have to program the remotes you have into this conversion kit. The Aladdin Connect will not need to be reprogrammed, it will work as normal.

  • How do I program two remotes? model girud-1t

    You will program each remote separately. One at a time, press and release the learn code button on the receiver box of the GIRUD-1T. Then take the remote, step a few feet away and press and release the button on the remote three to four times. The door will open or close. Then repeat with the second remote.

  • I have A 1/2 H.P Model ISD 1000 that only works off the wall unit only .. and the only light which comes on is red on panel...troubleshooting did not do...I assume the circuit card bad.com...where cab I find the number

    The circuit board that controls the remotes would be the 36600R.S control board

  • I have 2 Moore-O-Matic 838 garage door openers. They were likely installed in 1978 or 1979. It's a great opener but does not have the safety lasers. I have no remote openers that work. Will this conversion kit work? Can one be used with 2 doors?

    We cannot recommend updating any garage door opener without the installed safety beams, this will not work. One conversion kit will not work on two separate garage door openers.

  • Will this item be compatible with a #12A opener?

    Yes, it is.

  • Is this compatible with very old systems? I have a Genie opener from 1993 and looking to see if it is able to be upgraded. Works great still.

    Yes, this will work with a unit from 1993.

  • Is this compatible with Genie GT912 ? If yes is it easy to change it or has to be done by technician?

    The universal garage door opener remote upgrade/ conversion kit will work to replace the GT912 remote, however once installed, the GT912 remote will not work once it is installed. It will work with the new style Intellicode remote that comes with it, and any other Intellicode remote. It does come with instructions and is easy to install yourself.

  • can this be programed to my 2015 toyota camri

    Yes it can!

  • is this compatible with the lear car2u system?

    Yes it is!

Related products
