The Genie Company

Universal Push Button

Universal Push Button

Regular price $11.99 USD
Regular price Sale price $11.99 USD
Sale Sold out

Open and close your garage door with ease from inside the garage, thanks to the Genie Universal Wall Button. This non-lit door wall button is universally compatible with most major garage door opener brands and can be used in addition to any existing wall button or wall console.

Installation is quick and easy, and all mounting hardware and installation instructions are included. The non-lit wall button mounts to a side wall and wires directly to the garage door opener.

.

  • Operate Garage from Inside. This Genie universal non-lit wall button mounts on a garage side wall to operate the garage door from inside the garage.
  • Universally Compatible. This door wall button is universally compatible with most major garage door opener brands.
  • Additional Wall Button. This garage door wall button can be used in addition to any existing wall button or wall console.
  • Easy Installation. Installation is quick and easy, and all mounting hardware and installation instructions are included. Direct wiring to the garage door opener is required.
  • Compatibility. This universal wall push button is compatible with most pre-2011 Genie garage door openers, current Genie Series II garage door openers and most major garage door opener brands. Cannot be used on Series III generation Genie units or Liftmaster/Chamberlain/Craftsman 2.0.

    California Residents: Proposition 65 WARNING

SKU: 37644R

In Stock! Usually ships within 24 hours.

ASK A QUESTION View full details
Universal Push button for garage door openers used to open and close the garage door
Universal Push Button
$11.99

QUESTIONS & ANSWERS

Ask a Question
  • which wall opener to replace original opener model ISD990

    Thank you for your question!  Either the Series II wall console, 39165R or the Universal Push Button, 37644R will work.

  • How much wire is provided with the universal push button? Can additional wire be spliced in to that provided? I'm going to the third bay of my garage - about 40 ft.

    Our buttons/consoles do not include wiring.  You can purchase a roll of wiring in 25ft or 90ft lengths.

  • Are there seperate installations instructions to add a second push button? we currently have one push button and want to add a second one next to another door. Can you splice the second push button to the original push button, or should the second one be connectected directly to the power head?

    You can add a second push button, but it has to be a non-lit push button.  You can wire the wall button to the original wall button or all the way back to the head.

  • (1)Can the Universal Push Button 37644R be wired to the Genie 6170 main unit BWC WHITE/BLACK terminals for simple door open/close operation? Y/N (2)Or instead, can/does the Series II Push Button 29599S.S work on the Genie 6170's BWC terminals? Y/N (3)Or can I install your 39165R wired wall consul to the BWC terminal and place in parallel a simple non lighted push button? Y/N This is all assuming that the Wireless Wall Console 39902R is still installed. I am only confused because I believe the the Genie 6170 is series III but I see a question answered that the series II 39165R wired wall consul works on the Genie 6170. thank you.

    To answer all of your questions in order:
    1. Yes! The Universal Push-button 37644R can be wired to the Genie 6170 main unit BWC WHITE/BLACK terminals for simple door open/close operation.
    2. Yes! The Series II Push Button 29599S.S will work on the Genie 6170's BWC terminals.
    3. Yes! You can install the 39165R wired wall console to the BWC terminal and place in parallel a simple non-lighted push button (like the 37644R).
    The Genie 6170 is not a series III opener, it is a Series II opener. Any of the wired scenarios above can be installed and still use the 39902R wireless wall console as well.

  • It is not compatible with any unit of the following brands? Liftmaster/Chamberlain/Craftsman

    No, it is not.

  • There is more specific information about compatibility on the ll series and lll series units?

    What information are you looking for?

  • Does this replace model GWB product code 32569R

    Yes, it can replace the GWB.

  • Hi! I have 4 wires, black (lock?), ref, white, yellow. How do I connect these? I left the black off and connected the other three wires but now I think the light stays on always. Thanks, Sue

    If you had a four-wire wall console, you will connect two wires to each terminal on the universal push button. For assistance please contact Genie customer service at 1-800-354-3643.

  • The online assembly instructions for the GWC-R unlighted wall button identify its terminals with plus and minus signs. The button delivered (without instructions) has terminals marked B and W. Is W (white?) the connection for the white wire (minus in instructions)?

    Yes, the += B, the - = W.

  • I would like to have a separate button for the light and door. I initially had a wall console that had separate buttons but it broke and then was replaced by my home warranty provider with a single button wall console that does both functions at the same time. My genie garage opener is very very old (prior to federal door sensor requirements) but it still works. do you offer a wall console with two buttons for older garage openers or can i buy two universal one button wall console from your website and then wire one to the light wire and then wire the door wire to the other universal one button wall console?

    The universal push-button will only open/close the garage door. It will not operate the lights. We no longer have the 4 wire wall console, and we cannot support any garage door opener that does not have the required safe-t-beams.

  • What wall console will replace the 27884-R? It is 4-wire and about 25 years old.

    The Universal Push Button will replace the 4-wire wall console. We no longer have a deluxe wall console that will replace the 4-wire.

  • What wall mount will replace original medallion series with 4 wires

    This Universal push button will be the only accessory we have to replace the 4 wire wall console.

Universal Push Button Installation Instructions



PUSH BUTTON INSTALLATION



Warning:

Verify there is NO power to the opener before installing Wall Button wires and Wall Button.

Caution:

Staples which are too tight can cut or pinch wires. Cut or pinched wires can cause the Wall button to stop working. When using the insulated staples, make sure you fasten them only as tightly as needed to hold the wire snugly



1. Wall Button location.

• Wall Button location should be in direct sight of the door.

• It should be at least five feet (5') above the floor to prevent small children from operating door.

• It must be away from any moving parts. (You should NOT be able to reach the garage door while standing at Wall Button.)

• Wall Button board screw connections are polarized, (+) positive and (-) negative.



 2a. Wiring (If pre-wired).

• Locate Wall Button pre-wired wire ends (Fig. 3-1). (They should be located within the guidelines mentioned above.)

• Split and strip ends of wire (Fig. 3-2).

• Fasten wire to Wall Button board screws on the back of Wall Button.

– Striped wire to the + (plus) terminal.

– White wire to the - (minus) terminal.



2b. Wiring (If NOT pre-wired).

• Pick a convenient location for mounting Wall Button using the guidelines mentioned above (Fig. 3-1).

• Run the wire from the Wall Button to the powerhead (Fig. 3-1).

• Split and strip ends of wire (Fig. 3-2).

• Fasten wire to control board screws on the back of Wall Button. – Striped wire to the + (plus) terminal. – White wire to the - (minus) terminal.



Image of the Genie universal push button installation instructions
