Technical diagram view showing available replacement parts for Genie models 7053, 7135, 7155
-
Enlarge Image1 – 39356Y.S – Powerhead Cover, 7155
     41717R.S – Powerhead Cover, All D Models
2 – 38911A.S – Light Lens Cover, 7153, 7055 (non D Models)
     41689R.S – Light Lens Cover, D Models
3 – 41182T.S – Motor Assembly
4 – 39344R.S – Light Socket Assembly
     39719A.S – Light Socket Assembly (L Models)
5 – 39342R.S – Transformer, 120V
6 – 39731R.S - Circuit Board
7 – 38240A.S – Power Cord
8 – 38437A.S – Screws, M6-1x12 (3 pack)
9 – 8706G04.S – Screws, #8x5/16 (3 pack)
10 – 39732R.S - Wi-Fi Circuit Board
11 – 39735R.S – Optical Encoder (NIDEC Motor)
       41263R.S – Optical Encoder (RIDE Motor)
A - 111658.0002.S - Battery Only, Replacement
B - 39577R.S - Battery backup hardware, non D models
     41095R.S – Battery backup hardware, D Models
Not Shown - 38936A.S - Battery backup harness
-
Enlarge Image1 – 39410R.S – 5 Piece Rail, Chain 7’
     39411R.S – 5 Piece Rail, Belt 7’
2 – 39277R.S – Sprocket, Chain
     39278R.S – Sprocket, Belt
3 – 38893R.S – Carriage Assembly
4 – 39276R.S – Pulley Assembly
5 – 39352R.S – Chain Assembly, 7’
     39354R.S – Belt Assembly, 7’
     39352S.S – Chain Assembly, 8’
     39354S.S – Belt Assembly, 8’
6 – 37476A.S – Curved Door Arm
7 – 37475A.S – Straight Door Arm
8 – 39761A.S – Hanging Strap
A – 39010R.S – Mounting Parts Pack, Orange Bag
B – 39011R.S – Installation Parts Pack, Blue Bag
C – 39012R.S – Belt Retainer Parts, Clear Bag
D – 37105S.S – Hanging Hardware, Green Bag
Not Shown –
39027R – Rail Extender Kit, Chain, for 8’ high doors
-
Extension Kit (to 8') for 5 Piece, Belt Drive Tube Rails
Regular price $47.99 USDRegular priceUnit price per -
View Details
Belt/ Chain Drive Carriage Assembly- 38893R.S
Regular price $32.64 USDRegular priceUnit price per -
View Details
Replacement Belt for 7' Garage Door Opener- 39354R.S
Regular price $102.29 USDRegular priceUnit price per -
View Details
120 Volt Transformer- Model TDB-B100-2402 - 39342R.S
Regular price $54.79 USDRegular priceUnit price per -
Extension Kit (to 8') for 5 Piece, Chain Drive Tube Rails
Regular price $37.99 USDRegular priceUnit price per -
View Details
Curved Door Arm- 37476A.S
Regular price $6.19 USDRegular priceUnit price per -
View Details
Belt Drive Sprocket- 39278R.S
Regular price $24.48 USDRegular priceUnit price per -
View Details
Mounting Parts Pack (Orange Bag) - 39010R.S
Regular price $17.12 USDRegular priceUnit price per -
View Details
Pulley Assembly- 39276R.S
Regular price $15.99 USDRegular priceUnit price per -
View Details
Straight Door Arm- 37475A.S
Regular price $6.19 USDRegular priceUnit price per -
View Details
Battery BackUp Replacement Battery- 111658.0002.S
Regular price $59.99 USDRegular priceUnit price per -
View Details
Light Lens Cover- 38911A.S
Regular price $15.15 USDRegular priceUnit price per
